Short Description:

Stationary back-pulled air collet chuck DAS-16C for tapping machine drilling machine automatic equipment fixed pneumatic chuck

Product Name: back-pulled Stationary air collet chuck

Item NO: DAS-16C

Type: pneumatic chuck

Material: steel

MAX clamping size: 40mm

repeatability accuracy: within 0.015MM

match collet: 16C

Operation pressure: 3-15KG/cm2

gripping force: 4000kgf

packing size: 20*20*15cm

G.W: 12kgs

usage: Dental equipment,tapping machine, Automation equipment, drilling machine
